75 Inch Shopping Mall Wall Mount Full HD Window Facing LCD
Advertising Display Screen
75 Inch window advertising display Description
The FSHD750 displav has been designed to be installed inside retail
storerestaurant or
any window locations and face outwards, with high
brightnessperformance that is designed
to attract attention, evening during the daytime.lts low power
consumption and the silent fans
create low noise makes it extremelyenergy efficient.
75 Inch window advertising display Feature
◉ Increased Brightness
The brightness has been designed typical 2,500nitsit's 10times
brighter than normal family
TVs, it makesthe HD series the ultimate screen for outdoor
visibility.
◉ High Operating Temperature
The panel offers superb reliability under high
operatingtemperatures and reduces cooling fan usage.
◉ Silent Fan Noise Reduction
The HD Series is the perfect choice for an in-windovenvironment due
to the silent cooling fan.lts
operating noise level is under 25 dB, whichis quieter than a
typical recording (30 dB).
◉ Low Power Consumption Using
The M+ PanelThe M+ panel offers excellent energy efficiency andcost
savings and decreases power
consumptioncompared to conventional RGB panels.
◉ Smart Brightness Control
The auto brightness sensor adjust backlight brightnessaccording to
the ambient brightness to save
power energyand protect the human eye.
Parameter
| Screen Size | 75" (74.52" measured diagonally) |
| Panel Technology | IPS, M+ (WRGB) |
| Aspect Ratio | 16:09 |
| Native Resolution | 3,840 x 2,160 (UHD) |
| Brightness | 2,500 cd/m2 |
| Contrast Ratio | 1,200:1 |
| Viewing Angle (H x V) | 178 x 178 |
| Surface Treatment | Antiglare (Haze 3%), Hard coating (2H) |
| Lifetime | 50,000 Hrs Min. |
| Operation Hours | 24 Hrs |
| Orientation | Landscape & Portrait |
| Input | HDMI x 2, USB |
| Output | / |
| External Control | RS232C Optional |
| Bezel Color | Black |
| Bezel Width | 18.0 mm (T/B), 18.0 mm (L/R) |
| Monitor Dimension (W x H x D) | 1,468.6 x 843.6 x 85.0 mm |
| Weight (Head) | 45.0 kg |
| Carton Dimensions (W x H x D) | 1,620 x 1,000 x 230 mm |
| Packed Weight | 48 kg |
| VESATM Standard Mount Interface | 400 x 400 mm, 4 x M8 |
| Operation Temperature | 0°C to 45°C |
| Operation Humidity | 10% to 80% |
| Power Type | Built-In Power |
| Power Supply | 100-240 V~, 50/60 Hz |
| Power Consumption | 405 W / 450 W |
| / |
| Safety | / |
| EMC | FCC Class "A" / CE |
| Optional | Mounting Bracket: wall mount, floor stand, roof hanging |
| Basic | Remote control(w/o battery) ,AC power plug |
FAQ
1.Q: Are you a manufacturer or trading company?
A: We are a professional manufacturer specialized in high
brightness shop LCD panel/LCM
since 2016 located in Shenzhen.
2. Q: How long is the warranty?
A: Our officially promised warranty time is 1 year or
18months(Non-artificial damages) from
the date of delivery.
3. Q: Do you provide ODM/OEM or customized service?
A: We’re BOE High-bright LCD ODM factory, OEM/ODM are available
based on your requirements.
In order to support different customers, we are able to supply:
(1) High Brightness LCD Panel: LCD panel+led driver board+auto
dimming sensor
(2) Open Frame LCD Displays: LCD Panel+PSU+AD board(optional
interface, eg: HDMI, VGA,
DVI, USB...)+Touch optional
(3) Window Facing Displays: LCD Panel+PSU+AD board (network board
optional)+fan system+
temperature control board+housing
(4) Full Outdoor Displays: customized. eg: touch function,
IP55/IP65 etc.
4. Q: What brand of OC do you use?
A: Original LG/SAMSUNG/AUO/BOE etc. A or A+ grade OC, the shop window LCD screen display
we can guarantee each display will pass through strict quality
inspection.
5. Q:What certifications you have?
A:The CE-EMC Certificate of Conformity, ISO certification, FCC
certification.
6.Q:What is the temperature when the screen surface goes black?
A: Normal grade goes black over 68℃；industrial grade goes black
over 105 or 110℃.
7.Q: What is the MOQ?
A: Sample testing is acceptable, the price is negotiable for bulk
order.
8.Q: When will you delivery?
A: High brightness LCD panel sample order shipped in 3days, bulk
order shipped within 2 weeks.
