Best Sales 32 Inch Full HD Digital Signage Window Tint Wall Display
For Advertising Screen
32 Inch Digital Signage Window display Feature
◉ High Visibility Under Strong Sunlight
With stunning high brightness of 2,500 nits FSHD320 outdoor display
highlights the contents
clearly beyond the window. In addition, its outstanding visibility
can deliver a variety of information
even to those wearing polarized sunglasses.
◉ Wide Viewing Angle
Customers can enjoy the content vividly from various angle of the
window as they walk. The IPS
panel enables FSHD320 to have a wide viewing angle.
◉ Slim Design
FSHD320 attracts attention with elegant design, featuring a slim
bezel. Thanks to its thin depth,
FSHD320 takes up less space, which leads to space efficiency in an
in-window environment.
◉ Smart Brightness Control
The screen brightness is automatically adjusted depending on the
ambient light. The brightness
is increased in light for better visibility, while it is decreased
in darkness for efficient power management.
32 Inch Digital Signage Window display Parameter
| Specifications | FSHD320 |
| PANEL | Screen Size | 32 inch window digital display |
| Panel Technology | IPS, |
| Aspect Ratio | 16:09 |
| Native Resolution | 1,920 x 1,080 (FHD) |
| Brightness | 2,500 cd/m2 |
| Contrast Ratio | 1,300:1 |
| Viewing Angle (H x V) | 178 x 178 |
| Surface Treatment | Antiglare (Haze 3%), Hard coating (2H) |
| Lifetime | 50,000 Hrs Min. |
| Operation Hours | 24 Hrs |
| Orientation | Landscape & Portrait |
| CONNECTIVITY | Input | HDMI, VGA, USB, Audio |
| Output | / |
| External Control | RS232C Optional |
| PHYSICAL SPECIFICATION | Bezel Color | Black |
| Bezel Width | 18.0 mm (T/B), 18.0 mm (L/R) |
| Monitor Dimension (W x H x D) | 739.0 x 433.0 x 85.0 mm |
| Weight (Head) | 10.0 kg |
| Carton Dimensions (W x H x D) | 890 x 590 x 230 mm |
| Packed Weight | 12 kg (TBD) |
| VESATM Standard Mount Interface | 300 x 200 mm, 4 x M8 |
| ENVIRONMENTAL CONDITIONS | Operation Temperature | 0°C to 45°C |
| Operation Humidity | 10% to 80% |
| POWER | Power Type | Built-In Power |
| Power Supply | 100-240 V~, 50/60 Hz |
| Power Consumption | Typ. / Max. | 100 W / 110 W |
| Smart Energy Saving | / |
| STANDARD CERTIFICATION | Safety | / |
| EMC | FCC Class "A" / CE |
| ACCESSORIES | Optional | Mounting Bracket: wall mount, floor stand, roof hanging |
| Basic | Remote control(w/o battery) ,AC power plug |
| WARRANTY | WARRANTY | 18Month, Free spare parts, Technical support |
FAQ
1.Q: Are you a manufacturer or trading company?
A: We are a professional manufacturer specialized in window digital
display LCD panel/LCM
since 2016 located in Shenzhen.
2. Q: How long is the warranty?
A: Our officially promised warranty time is 1 year or
18months(Non-artificial damages) from
the date of delivery.
3. Q: Do you provide ODM/OEM or customized service?
A: We’re BOE High-bright LCD ODM factory, OEM/ODM are available
based on your requirements.
In order to support different customers, we are able to supply:
(1) High Brightness LCD Panel: LCD panel+led driver board+auto
dimming sensor
(2) Open Frame LCD Displays: LCD Panel+PSU+AD board(optional
interface, eg: HDMI, VGA,
DVI, USB...)+Touch optional
(3) Window Facing Displays: LCD Panel+PSU+AD board (network board
optional)+fan system+
temperature control board+housing
(4) Full Outdoor Displays: customized. eg: touch function,
IP55/IP65 etc.
4. Q: What brand of OC do you use?
A: Original LG/SAMSUNG/AUO/BOE etc. A or A+ grade OC, we can guarantee each window digital
display will pass through strict quality inspection.
5. Q:What certifications you have?
A:The window digital display CE-EMC Certificate of Conformity, ISO
certification, FCC certification.
6.Q:What is the temperature when the screen surface goes black?
A: Normal grade goes black over 68℃；industrial grade goes black
over 105 or 110℃.
7.Q: What is the MOQ?
A: Window digital display sample testing is acceptable, the price
is negotiable for bulk order.
8.Q: When will you delivery?
A: High brightness LCD panel sample order shipped in 3days, bulk
order shipped within 2 weeks.
