55inch high brightness shop storefront window display window lcd
digital screen
Window LCD Display Description
1. Window LCD Display attracts attention with elegant design,
featuring a slim bezel and depth.
The even bezel at 18mm and whole machine depth at 85mm, very slim
and thin design for every
storefront window environment. These displays enhance the visual
impact of the played content
and the store’s overall atmosphere.
2. Window lcd display series was designed with a storefront window
display in mind. It projects
clear, bright images that attract and engage audiences, increasing
the probability of an in-store
visit with its 5000 nits(Max.). Window LCD Display designed with high temperature resistant OC
superior durability for all weather conditions which can leave a
deep impression even in the
brightest sunlight, without black mura.
3. Its operating noise level is under 25dB, which is quieter than
that of typical daily conversation.
Thanks to the built-in quiet operation cooling fans, we have made
the HD series Window LCD
Display an ideal choice for the in-window environment.
Window LCD Display Parameter
| PANEL | 55" |
| IPS, |
| 16:09 |
| 1,920 x 1,080 (FHD) |
| 2,500 cd/m2 |
| 1,000:1 |
| 178 x 178 |
| Hard coating (2H), Reflection 1.5% (Typ.) |
| 50,000 Hrs Min. |
| 24 Hrs |
| Landscape & Portrait |
| CONNECTIVITY | HDMI, VGA, USB, Audio |
| / |
| RS232C Optional |
| PHYSICAL SPECIFICATION | Black |
| 18.0 mm (T/B), 18.0 mm (L/R) |
| 980.0 x 568.0 x 85.0 mm |
| 31.0 kg |
| 1,390 x 900 x 230 mm |
| 33.0 kg |
| 400 x 400 mm, 4 x M8 |
| ENVIRONMENTAL CONDITIONS | 0°C to 45°C |
| 10% to 80% |
| POWER | Built-In Power |
| 100-240V~, 50/60Hz |
| 162 W / 180 W |
| / |
| STANDARD (CERTIFICATION) | / |
| FCC Class "A" / CE |
| ACCESSORIES | Mounting Bracket: wall mount, floor stand, roof hanging |
| Remote control(w/o battery) ,AC power plug |
| WARRANTY | 18Month, Free spare parts, Technical support |
Window LCD Display Drawing
Window LCD Display Applications
Financial institutions, Public places:
bookstores, exhibition halls, stadiums, museums, conference
centers, talent markets, etc .;
Entertainment and leisure:
cinemas, fitness gyms, resorts, entertainment venues, foot baths,
KTV bars,beauty salons,
golf courses, etc .;
Industrial sites:
food processing equipment, machinery control, office automation
equipment, automated
testing,automotive testing equipment, etc .;
Transportation place:
bus station, passenger station, subway, high-speed rail, airport,
etc .
Medical places:
hospitals, medical institutions, pharmacy chain institutions, etc.
FAQ
1.Q: Are you a manufacturer or trading company?
A: We are a professional manufacturer specialized in Window LCD
Display since 2016 located
in Shenzhen.
2. Q: How long is the warranty?
A: Our officially promised warranty time is 1 year or
18months(Non-artificial damages) from
the date of delivery on Window LCD Display.
3. Q: Do you provide ODM/OEM or customized service?
A: We’re BOE High-bright LCD ODM factory, OEM/ODM are available
based on your requirements.
In order to support different customers, we are able to supply:
(1) High Brightness LCD Panel: LCD panel+led driver board+auto
dimming sensor
(2) Open Frame LCD Displays: LCD Panel+PSU+AD board(optional
interface, eg: HDMI, VGA,
DVI, USB...)+Touch optional
(3) Window Facing Displays: LCD Panel+PSU+AD board (network board
optional)+fan system+
temperature control board+housing
(4) Full Outdoor Displays: customized. eg: touch function,
IP55/IP65 etc.
4. Q: What brand of OC do you use?
A: Original LG/SAMSUNG/AUO/BOE etc. A or A+ grade OC, we can guarantee each display will
pass through strict quality inspection on Window LCD Display.
5. Q:What certifications you have?
A:The Window LCD Display CE-EMC Certificate of Conformity, ISO
certification, FCC certification.
6.Q:What is the temperature when the screen surface goes black?
A: Normal grade goes black over 68℃；industrial grade goes black
over 105 or 110℃.
7.Q: What is the MOQ?
A: Window LCD Display Sample testing is acceptable, the price is
negotiable for bulk order.
8.Q: When will you delivery?
A: High brightness LCD panel sample order shipped in 3days, bulk
order shipped within 2 weeks.
