86inch Large size display 700nits-3500nits indoor high brightness
window facing advertising display
86 Inch window advertising display Description
The FSHD860 displav has been designed to be installed inside retail
storerestaurant or
any window locations and face outwards, with high
brightnessperformance that is designed
to attract attention, evening during the daytime.lts low power
consumption and the silent fans
create low noise makes it extremelyenergy efficient.
86 Inch window advertising display Feature
◉ High Brightness
LCD backlight brightness 700-3500nits. Meets the best viewing
requirements under direct sunlight.
◉ Industrial grade LCD
The LCD panel is high Tni 110 degree with wide temperature. It
doesn’t turn black under direct sunlight.
◉ Polarized sunglasses are visible
LCD panel uses QWP technology to improve visibility. Wearing
polarized sunglasses doesn't affect effect.
◉ Low noise design
Low noise design, especially suitable for window environment. Below
25dB, the sound is as quiet as in a recording studio.
◉ Industrial Ultra-thin Design
Narrow frame, can be used for multiple screens. Ultra-thin,
suitable for storefront info display.
Brushed frame, more fashionable appearance.
◉ Smart Brightness Control
The auto brightness sensor adjust backlight brightness according to
the ambient brightness to save power energyand protect the human
eye.
Parameter
| Screen Size | 86" |
| Panel Technology | IPS, M+ (RGB) |
| Aspect Ratio | 16:09 |
| Native Resolution | 3,840 x 2,160 (UHD) |
| Brightness | 700cd/m2 - 3500 cd/m2 |
| Contrast Ratio | 1,200:1 |
| Viewing Angle (H x V) | 178 x 178 |
| Surface Treatment | Haze 3% |
| Lifetime | 50,000 Hrs Min. |
| Operation Hours | 7*24 Hrs |
| Orientation | Landscape & Portrait |
| Spec | 3288 2+16GB or 3568 2+16GB |
| Interface | HDMI-in*1/ USB*1/ RJ45*1 DC12V |
| Bezel Color | Black |
| Bezel Width | 18.0 mm (T/B), 18.0 mm (L/R) |
| Monitor Dimension (W x H x D) | 1935.0*1106*85mm |
| Weight (Head) | 48.0 kg |
| Carton Dimensions (W x H x D) | 1,800 x 1,100 x 220 mm |
| Packed Weight | 68kg |
| VESATM Standard Mount Interface | 600 x 400 mm |
| Operation Temperature | 0°C to 40°C |
| Operation Humidity | 10% to 85% |
| Power Type | Built-In Power |
| Power Supply | 180-264V, 50/60Hz |
| Power Consumption | 960 W |
FAQ
1.Q: Are you a manufacturer or trading company?
A: We are a professional manufacturer specialized in high
brightness shop LCD panel/LCM
since 2016 located in Shenzhen.
2. Q: How long is the warranty?
A: Our officially promised warranty time is 1 year or
18months(Non-artificial damages) from
the date of delivery.
3. Q: Do you provide ODM/OEM or customized service?
A: We’re BOE High-bright LCD ODM factory, OEM/ODM are available
based on your requirements.
In order to support different customers, we are able to supply:
(1) High Brightness LCD Panel: LCD panel+led driver board+auto
dimming sensor
(2) Open Frame LCD Displays: LCD Panel+PSU+AD board(optional
interface, eg: HDMI, VGA,
DVI, USB...)+Touch optional
(3) Window Facing Displays: LCD Panel+PSU+AD board (network board
optional)+fan system+
temperature control board+housing
(4) Full Outdoor Displays: customized. eg: touch function,
IP55/IP65 etc.
4. Q: What brand of OC do you use?
A: Original LG/SAMSUNG/AUO/BOE etc. A or A+ grade OC, the shop window LCD screen display
we can guarantee each display will pass through strict quality
inspection.
5. Q:What certifications you have?
A:The CE-EMC Certificate of Conformity, ISO certification, FCC
certification.
6.Q:What is the temperature when the screen surface goes black?
A: Normal grade goes black over 68℃；industrial grade goes black
over 105 or 110℃.
7.Q: What is the MOQ?
A: Sample testing is acceptable, the price is negotiable for bulk
order.
8.Q: When will you delivery?
A: High brightness LCD panel sample order shipped in 3days, bulk
order shipped within 2 weeks.
